CC7 North Non-Destructive Testing (NDT) Plan and Data

NDT Testing was divided into three areas: Pre-Traffic Testing; Testing During Trafficking; and Post Traffic Testing.

Pre-Traffic Testing

Prior to the start of traffic testing, the NDT team performed the following tasks:

a.   2D/3D Imaging.  With the use of the NDT Van, collected 2D/3D image data across the entirety of the CC7 test sections from East to West.

Imaging system on NDT van

b.   Mobile Profiler.  Took longitudinal profiles using the NDT van mobile profiler.  All profiles were taken at the same time as the 2D/3D imaging.  Locations of longitudinal and transverse profiles are shown in the CC7 NDT Plan below.
